Using the Auto-Arrange feature

TimeMap includes an Auto-Arrange feature that helps eliminate instances when fact boxes overlap each other in the timeline. As you enter facts, the Auto-Arrange feature automatically repositions existing fact boxes horizontally and vertically, add timeline pages, and add time scale breaks to eliminate or minimize instances of overlapping.

Sometimes fact flags get positioned on page breaks. While they can be moved to a new location, TimeMap has a feature that eliminates the need to relocate them in most cases. If a flag is located on a page break and then does not print entirely on a page, TimeMap will repeat the flag from its start point on the subsequent page. This is default behavior for both printed and PDF output.



hmtoggle_plus1To auto-arrange fact boxes
1.On the Box Tools Format ribbon, click Auto-Arrange.

If you are not happy with the results, click the Undo button TM_undo_button.

hmtoggle_plus1To change Auto-Arrange options
1.On the File menu, click Options.
2.In the Options dialog box, click the Auto-Arrange tab.

Options > Auto-Arrange

3.Select check boxes for the options you want enabled.
4.Clear check boxes for the options you want disabled.
5.Click OK to save your changes.



related_topics_buttonRelated Topics
